Double Coated Tape Polyester 7
Home || Double Coated Tape Polyester 7
Double Coated Polyester Tapes...
IT1114...
Polyester (Clear)
3.5 mil (0.09mm) exclusive of liner. 0.5 mil thin clear polyester film coated on both sides with an aggressive synthetic hot melt rubber adhesive, and wound on a 2.7 mil white siliconized paper release liner.
Superior moisture resistance in humid conditions once bonded. Excellent quick-stick. Ideal for laminating difficult substrates and various webs, such as foams and foils. Perfect for splicing of papers, plastics, films, foils, etc. Used in general-purpose bonding and mounting (e.g., nameplates, mouse pad assembly).
Adhesion to SST: 64 oz/in.
Elongation: 130%
Environmentally friendly; solventless adhesive.
Temperature Resistance: -4°F to 140°F
3" neutral core/carton.
WIDTH :
1-2
RLS/CS :
3-11
CASES :
12+
60 YD (55MJ)
Alternative to Adchem #3175M; Venture #512; Scapa #S-662.
54" (1370mm) x approx. 1000M Jumbos Available.
IT4106LW...
Polyester (Clear) — 60 YD (55M)
2.4 mil (0.06mm) exclusive of liner. 0.5 mil clear polyester film coated on both sides with a modified solvent-free water-based acrylic adhesive. Light blue siliconized paper liner.
Adheres to most materials, even difficult surfaces like foams and PE film. Good alternative to adhesive transfer tapes as it is thin, hand-tearable, and easier to apply by hand.
Very good temperature, UV, aging, and water vapor resistance. No plasticizer migration.
Can be used for splicing, bonding, and laminating paper, corrugated paper, films, plastics, foils, etc. For mounting nameplates, keyboard assemblies; laminating various webs.
Adhesion: >47 oz/in.
Alternative to: Tesa #4972
Temperature Resistance: -40°F to 212°F
3" neutral core/carton.
60 YD (55M)
Alternative to Tesa #4972. 39.4" (1000mm) x 1000M Jumbos Available.
IT4109CS/G
Polyester (Clear) —
3.5 mil (0.09mm) exclusive of liner. 0.5 mil clear polyester film coated on both sides with an aggressive, quick-stick, high-peel and high-shear strength, solvent-free water-based adhesive.
Gold glassine paper release liner. Excellent moisture resistance in high humidity; temperature, UV, and aging resistance.
Wide web width for laminating jobs.
For high-speed flying splice of paper, corrugated paper, plastics, films, foils, etc.; mounting nameplates, keyboard assembly; laminating dissimilar metals; automotive.
applications. Adhesion: >44 oz/in. Temperature Resistance:
-40°F to 392°F. 3" neutral core/carton.
IT4109cs.
Polyester (Clear)
3.5 mil (0.09mm) exclusive of liner. 0.5 mil clear polyester film coated on both sides with an aggressive quick-stick, high-peel, and high-shear strength, solvent-free water-based acrylic adhesive.
White glassine paper release liner. Superior moisture resistance in high humidity.
High-speed flying splice of paper, corrugated paper, plastics, films, foils, etc.; mounting nameplates, keyboard assembly; laminating dissimilar metals.
Adhesion: >44 oz/in
Temperature Resistance: -40°F to 392°F
3" neutral core/carton.
60 YD (55M)
Alternative to Venture #514CW & #518; 3M #415; Adchem #254M; Anchor #593;
IT4109/R..
Polyester (Bright Red)
3.5 mil (0.09mm) exclusive of liner. 0.5 mil bright red polyester
film coated on both sides with an aggressive, clear acrylic adhesive. White kraft paper liner. High tack/adhesion/shear strength, excellent temperature performance. For splicing paper, plastics, films, foils, low/high energy surfaces, and continuous web processes when a visual splice is critical. Adhesion: 95 oz/in. Tack: 77 oz/in. Elongation: 110%. Temperature Resistance: -22°F to 320°F (428°F short term). 3" neutral core/carton.
-46-
YD (55M)
Alternative to Venture #515R; 3M #9420 & #9737R; Berry Global #756; lnt'I Tape #713R; Scapa #5234R; Newbond #TF2404.
4.
ATP PL#33.12 v2023.03.09
