High Bond Tapes Data
Home || High Bond Tapes Data
Ultra High Bond Tapes
Double Coated Acrylic Foam IT560C
CLEAR Foamed Acrylic Tape
59 mils (1.5mm) exclusive of liner. Clear foamed acrylic with RED PE liner. Ideal for all around bonding in the most demanding appli cations. 90° Peel Adhesion: 215 oz/in (20 min); 258 oz/in (24 hrs). Tensile Strength: 66 lb/in'. Dynamic Shear (SST): 77 lb/in'. Temperature Resistance: -40°F to 392°F. UV Resistance: Good.
3" plastic core.
27.34 YD (82 FT) 25M
Alternative to 3M #4915; ADCO #1160; Hi-Bond #4150C.
IT560GY
GRAY Foamed Acrylic Tape
59 mils(1.5mm) exclusive of liner. Gray foamed acrylic adhesive with RED PE liner. Ideal for all around bonding in the most demanding applications. 90° Peel Adhesion: 233 oz/in (20 min); 412 oz/in (24 hrs). Tensile Strength: 99 lb/in'. Dynamic Shear (SST): 121 lb/in'. Temperature Resistance: -40°F to 356°F. UV Resistance: Good. 3" plastic core.
27.34 YQ (82 FTJ 25M
Alternative to 3M #4956, #4979F, #5356, #5567 #5962; ADCO #4655, #4956; Hi-Bond #6150G; ORABOND #3603.
IT561C
CLEAR Foamed Acrylic Tape
79 mils (2.0mm) exclusive of liner. Clear foamed acrylic adhesive with RED PE liner. Ideal for all around bonding in the most demanding applications. Used for structural bonding applications, bonding plastic and wooden window glazing bars, fixing architec tural panels. 90° Peel Adhesion: 226 oz/in (20 min); 287 oz/in (24 hrs). Tensile Strength: 66 lb/in'. Dynamic Shear (SST): 66 lb/in'. Temperature Resistance: -40°F to 392°F. UV Resistance: Good.
3" plastic core.
18 YD (54 FT} 16.5M
Alternative to 3M #4918; Hi-Bond #4200C.
IT561GY..
GRAY Foamed Acrylic Tape
79 mils (2.0mm) exclusive of liner. Gray foamed acrylic adhesive
with RED PE liner. Ideal for structural bonding applications in the transportation industry; fixing body & roof panels in the bus and truck industry, mounting/fixing car side molding & emblems. go0 Peel Adhesion: 215 oz/in (20 min); 358 oz/in (24 hrs). Tensile Strength: 99 lb/in'. Dynamic Shear (SST): 121 lb/in'. Temperature
Resistance: -40°F to 356°F. UV Resistance: Good. 3" plastic core.
1§ YD (§4_ FT) 16.5M
Alternative to 3M #4991; Hi-Bond #6200G; ORABOND #3602.
IT562W .
WHITE Foamed Acrylic Tape
79 mils (2.0mm) exclusive of liner. White foamed acrylic adhesive with RED PE liner. Ideal for all around bonding in the most demanding applications. Used for structural bonding applications, bonding plastic and wooden window glazing bars, fixing architec
tural panels. 90° Peel Adhesion: 215 oz/in (20 min); 358 oz/in (24hrs). Tensile Strength: 99 lb/in'. Dynamic Shear (SST): 121 lb/in'.
Temperature Resistance: -40°F to 356°F. UV Resistance: Good. 3" plastic core.
18 YD ( 4 FT) 16.5M
Alternative to 3M #4912; ADCO #4955; Hi:Bond #4200W.
IT563W.
WHITE Foamed Acrylic Tape
118 mils (3.0mm) exclusive of liner. White foamed acrylic adhesive with RED PE liner. Ideal for structural bonding applications in the transportation industry; fixing body and roof panels in the bus and truck industry, mounting/fixing car side molding and emblems. go0
Peel Adhesion: 215 oz/in (20 min); 358 oz/in (24 hrs). TensileStrength: 99 lb/in'. Dynamic Shear (SST): 121 lb/in'. Temperature
Resistance: -40°F to 356°F. UV Resistance: Good. 3" plastic core.
18 YD (54 FT) 16-5M
Alternative to 3M #4959; Hi-Bond #6300W.
